eFlow®rapid Nebuliser System with eBase® Controller

Patients worldwide benefit from clinically tested eFlow® Technology

The eFlow®rapid nebuliser system is suitable for the treatment of a wide range of diseases of the lower airways. It is used for an efficient and fast inhalation in long-term treatment.

  • The eFlow membrane technology offers short nebulisation time [1]
  • Small, lightweight, mobile and silent for discreet use
  • Hygiene: easy to clean and disinfect
  • Display provides feedback during inhalation
  • High lung dose correlates with good efficacy with standard nebuliser solutions [2,3]

[1] Naehrig S et al. Eur J Med Res 2011; 16(2): 63-6
[2] Beck-Broichsitter, M. J Pharm Sci, 2017. 106(8): p. 2168-2172
[3] Beck-Broichsitter M et al. Eur J Pharm Biopharm 2014; 87(3): 524-9

Preparing and performing inhalation with the eFlow®rapid nebuliser system.

Wash your hands thoroughly.

Clean the nebuliser handset and aerosol head before the first application.

All parts must be completely dry before they are assembled.

Insert the aerosol head (1) into the openings on the medication reservoir and place the inspiratory valve (2) onto the aerosol chamber. Take care not to touch the membrane (curved metal surface in the centre of the aerosol head). Attach either the mouthpiece, the SMARTMASK Baby with bend, the SMARTMASK Kids or the adult SMARTMASK.

Connect the nebuliser handset and controller with the connection cord (4). The controller can be powered by either mains or batteries.



Add the inhalation solution or medication and attach the medication cap. Warning: Check that all parts are connected tightly and that the medication reservoir is sealed.

Sit upright in a relaxed position and pick up the nebuliser handset.





Put the mouthpiece between your teeth and close your lips around it.









Switch on the device. A beep indicates that the device has started.








Inhale and exhale slowly and deeply through the mouthpiece. Hold the mouthpiece in your mouth while breathing out as well. Hold the nebuliser horizontally.

If using a mask, place it over your mouth and nose, applying light pressure for a snug fit. Ensure that the nebuliser handset is horizontal.

The controller switches off automatically once no more aerosol is generated. The inhalation session has ended.



At the end of the treatment session about 1 ml of the medication (must be discarded) remains in the handset. This is normal and ensures that the dose of medication is correct.

Always observe the instructions for use when using, cleaning or disinfecting your eFlow®rapid nebuliser system.

Download instructions for use

Aerosol characteristics of the eFlow®rapid nebuliser system

MMADa):4,7 µm
Respirable Fractiona) < 5 µm:53,8 %
Aerosol Output Rateb):0,43 g/min

Aerosol data according to ISO 27427; nebulised medium: Salbutamol 2.5 ml. Measured values may vary depending on the medication used. Recommended fill volume: see package leaflet for the medication.

a) Measurement with Next Generation Pharmaceutical Impactor (NGI) at 23 °C and 50% relative humidity. Inspiratory flow: 15 l/min

b) Measurement with breathing simulator at 23 °C and 50 % relative humidity. 500 ml breathing volume, breathing frequency 15 cycles/minute, sinusoidal breathing pattern, inhalation/exhalation ratio 1:1 (with adults, may vary in children).

For more technical information please see the Instructions for use.

All Year Packs can be purchased from your local PARI retailer.

eFlow®rapid mouthpiece

Item No.: 078G3601

eFlow®rapid aerosol head

Item No.: 678B2620

PARI easycare

Item No.: 078G6100

eFlow®rapid nebuliser connection cord

Item No.: 178G6009

eFlow®rapid AC adapter international

Item No.: 078B7114

All spare parts can be purchased from your local PARI retailer.

PARI Filter Valve Set

Item No.: 041G0500

PARI Tracheo Mask

Item No.: 025G0008

PARI SMARTMASK® Baby including bend

Item No.: 078G5026

PARI SMARTMASK® Kids

Item No.: 078G5000

PARI SMARTMASK®

Item No.: 041G0730

eFlow®rapid cotton bag for nebuliser

Item No.: 078E8000

eFlow®rapid carrying bag

Item No.: 078E8005

All Accessories can be purchased from your local PARI retailer.

Item No.: 178G1005

Using the eFlow®rapid correctly

Click on the video links below to find out more about the topics listed. Please always follow the respective instructions for use.

  1. Introduction of the eFlow®rapid nebuliser system and inhalation with the device
  2. Cleaning and disinfection
  3. Using the PARI Filter Valve Set with the eFlow®rapid nebuliser handset
  4. Cleaning the eFlow®rapid aerosol head with the PARI easycare cleaning aid

Please note: When you click on a link, you leave our homepage and open a YouTube page. For more information, please see our Privacy Policy.
