The PARI BOY Pro is designed for patients who need a comprehensive range of extra features and equipment.
Item No.: 130G1001 (Westerm Europe) IFU languages de, fr, it, pt, es, nl, en, – 130G1006 (Estern Europe) IFU Languages cs, el, hu, pl, sk, sl
Instructions for use
de, en, es, fr, it, nl, pt
130D2200-E 2019-07-01
Instructions for use
cs, el, hu, pl, sk, sl,
130D2201-E 2019-07-02
Aerosol characteristics of the PARI BOY Pro Compressor in combination with the PARI LC SPRINT Nebuliser (blue nozzle attachment):
| Total Output Rate: | 600 mg/min |
| MMD: | 3.5 µm |
| Mass fractions < 5 µm: | 67 % |
Aerosol characteristics of the PARI BOY Pro Compressor in combination with the PARI LC SPRINT Nebuliser (red nozzle attachment):
| Total Output Rate: | 450 mg/min |
| MMD: | 2.2 µm |
| Mass fractions < 5 µm: | 89 % |
Measurement with the Malvern Mastersizer X at 23°C and 50% relative humidity. Nebulised medium: 0.9% NaCl (5ml). Inspiratory flow 20l/min.
| Technical data for the compressor: | |
| Alternating current | 220-240 V~ 50 Hz |
| Housing dimensions (B x H x T): | 18.5 x 13 x 15 cm |
| Weight: | 1.7 kg |
| Pressure: | 1.6 bar |
| Guarantee: | 4 Years |
Spare parts: All spare parts can be purchased from your local PARI retailer.
